PIONEER MAGNETICS PM3398B-6P-1-3P-E | Industrial Power Supply Module

  • Model: PM3398B-6P-1-3P-E
  • Brand: Pioneer Magnetics
  • Series: Industrial Power Supply
  • Core Function: High-efficiency AC-to-DC power conversion
  • Type: Industrial Power Module
  • Key Specs: 240V AC input, 240W output, 23A rated current
Category: SKU: PIONEER MAGNETICS  PM3398B-6P-1-3P-E 80026-172-03

Description

Key Technical Specifications

  • Manufacturer: Pioneer Magnetics
  • Model Number: PM3398B-6P-1-3P-E
  • Manufacturer Part Number: 80026-172-03
  • Input Voltage: 240V AC
  • Output Voltage: 13V DC
  • Rated Current: 23A
  • Rated Power: 240W
  • Protection Features: Overload and short-circuit protection
  • Compliance: CE, CSA C22.2, ITE IEC/UL/EN60950



Product Introduction

PIONEER MAGNETICS PM3398B-6P-1-3P-E is a 240W industrial power supply designed for demanding automation environments. It converts 240V AC input into a stable 13V DC output at 23A for PLC and DCS systems.Field replacements demand precise matching. We verify the 80026-172-03 part number and test conversion efficiency before shipment. Each unit undergoes a 24-hour load test to confirm it handles peak current without voltage drop.

Installation & Configuration Guide

Preparation (10 min)

  • Lock out and tag out the main AC power source.
  • Verify the incoming 240V AC supply is within the specified tolerance.
  • Gather a #2 Phillips screwdriver and an anti-static wrist strap.
  • Locate the wiring diagram for the power supply slot.

Removal (5–10 min)

  • Attach the anti-static wrist strap to a grounded point.
  • Label all AC input and DC output wires before disconnecting.
  • Loosen the terminal block screws.
  • Unmount the old power supply from the DIN rail or chassis.

Installation (10 min)

  • Inspect the mounting rail and terminal blocks for damage.
  • Slide the new PM3398B-6P-1-3P-E module into position.
  • Reconnect field wires exactly as labeled.
  • Tighten terminal screws securely. (I once saw a loose AC input terminal arc and melt the housing during a power surge.)

Power-On & Test (10 min)

  • Remove lockout devices and restore 240V AC power.
  • Measure the DC output terminals. Confirm 13V DC ±5%.
  • Check the system HMI for power supply health indicators.
  • Monitor the module temperature during the first 15 minutes of operation.



Troubleshooting Quick Reference

  • No DC output voltage: Check the 240V AC input at the terminal block. Measure for proper voltage. If input is good but output is dead, the internal rectifier or fuse has likely failed.
  • Output voltage is low or fluctuating: Measure the connected load current. An overloaded power supply will drop voltage. Ensure the 23A limit is not exceeded.
  • Module is excessively hot: Check for blocked ventilation. Industrial power supplies require airflow. Measure ambient temperature inside the enclosure.
  • System intermittently reboots: Inspect the DC output wiring for loose connections. A high-resistance joint can cause voltage sags during peak load.
  • Short-circuit protection triggered: Disconnect the DC load. Measure resistance across the output terminals. A reading near zero ohms indicates a shorted downstream device.

Dimensions, Mounting & Wiring Notes

  • Mounting Method: Standard DIN rail or chassis mount
  • Input Connection: AC Line, Neutral, and Ground terminals
  • Output Connection: High-current DC output terminals
  • Terminal Notes: Use appropriately sized copper wire for 23A continuous load. Torque terminals to manufacturer specification to prevent thermal runaway.



FAQ

Will the 80026-172-03 suffix affect my installation?
Yes. The suffix often indicates specific pinout, voltage trim, or certification variations. Always match the exact 80026-172-03 number to avoid wiring mismatches.I installed the module but the 13V output reads 11V. What now?
Check the load current immediately. The power supply may be in current-limiting mode due to an overload or short circuit. Disconnect the load and measure the open-circuit voltage.Do you offer a discount for bulk purchases?
Volume pricing applies. Send your exact quantity to our sales team for a formal quote. Lead times depend on current surplus inventory levels.Is this module factory sealed or refurbished?
This is New Surplus. It is factory sealed but may have been in warehouse storage. We perform a full 24-hour functional load test before shipping to guarantee it meets operational specs.What happens if the power supply trips its short-circuit protection?
The module is designed to shut down safely to prevent fire or damage. You must identify and clear the downstream fault before the supply will reset and resume normal operation.How long does shipping usually take?
We ship verified stock within 24 hours of payment. Transit times depend on your location and chosen freight carrier. Expedited options are available at checkout.Can this power supply handle a 240W continuous load?
Yes, it is rated for 240W continuous output. However, we recommend maintaining a 20% capacity margin in your system design to account for aging components and peak transients.
