HONEYWELL TC-CCN014 | Verified Authentic CNI Spare Part
HONEYWELL TC-CCN014 | Verified Authentic CNI Spare Part - Image 2
HONEYWELL TC-CCN014 | Verified Authentic CNI Spare Part - Image 3

HONEYWELL TC-CCN014 | Verified Authentic CNI Spare Part

  • Model: TC-CCN014
  • Brand: Honeywell
  • Series: Experion C300 Controller System
  • Core Function: Single media network communication interface
  • Type: CNI (Controller Network Interface) Module
  • Key Specs: Single media Ethernet, C300 controller compatible
Category: SKU: HONEYWELL  TC-CCN014

Description

Key Technical Specifications

  • Manufacturer: Honeywell
  • Model Number: TC-CCN014
  • Module Type: CNI (Controller Network Interface)
  • Network Media: Single Media Ethernet
  • System Compatibility: Experion C300 Controller
  • Mounting Style: C300 Backplane / IOTA Baseboard
  • Condition: New Surplus (Factory Sealed)



Product Introduction

HONEYWELL TC-CCN014 is a Controller Network Interface (CNI) module designed for the Experion C300 controller system. It handles single media network communication to ensure reliable data exchange between controllers and the host system.Field replacements require exact media type matching. Installing a single media module in a redundant media slot will cause communication failures. We verify the exact part number and test network handshakes before shipment.

Installation & Configuration Guide

Preparation (10 min)

  • Lock out and tag out the C300 controller rack.
  • Verify the system configuration requires a Single Media CNI module.
  • Gather a #2 Phillips screwdriver and an anti-static wrist strap.
  • Locate the specific slot assignment for the CNI module.

Removal (5–10 min)

  • Attach the anti-static wrist strap to a grounded point.
  • Label all Ethernet network cables before disconnecting.
  • Loosen the captive screws on the module faceplate.
  • Pull the module straight out. Avoid twisting the backplane pins.

Installation (10 min)

  • Inspect the backplane connector for bent pins or debris.
  • Slide the new TC-CCN014 module into the designated slot.
  • Reconnect the network cables to the correct ports.
  • Tighten the captive screws securely. (I once saw a slightly loose faceplate screw cause intermittent grounding issues that took hours to trace.)

Power-On & Test (10 min)

  • Remove lockout devices and restore power to the C300 rack.
  • Observe the module LEDs. A steady green indicates normal network link.
  • Check the Experion HMI for active communication faults.
  • Verify data update rates between the controller and host.



Troubleshooting Quick Reference

  • Module has no LED indicators: Check the backplane power. Ensure the C300 controller is fully seated and the rack power supply is functioning.
  • Flashing red network LED: Indicates a communication loss or network fault. Verify the Ethernet cable integrity and check the switch port configuration.
  • HMI shows controller offline: Confirm the module is TC-CCN014 (Single Media) and not TC-CCR014 (Redundant). A media mismatch will prevent the controller from establishing a link.
  • Intermittent data drops: Inspect the Ethernet cable for ESD damage or loose crimps. Verify that the cable length does not exceed standard Ethernet limits.
  • Module runs hot to the touch: Check for blocked ventilation around the C300 rack. Ensure the control panel cooling fan is operational and ambient temperature is within spec.

Dimensions, Mounting & Wiring Notes

  • Mounting Method: Proprietary Experion C300 backplane slot
  • Network Connection: Standard RJ45 Ethernet port (Single Media)
  • Terminal Notes: Use shielded Ethernet cables for industrial environments. Ensure proper grounding to prevent EMI interference.



FAQ

Will the TC-CCN014 work if my old module was a TC-CCR014?
No. The TC-CCN014 is a Single Media module, while the TC-CCR014 is Redundant Media. They are not interchangeable. Installing the wrong media type will cause a complete network failure.I installed the module but the network LED stays red. What now?
Check the physical Ethernet connection first. Ensure you are plugged into the correct port and that the network switch is configured properly. Also, verify that the C300 controller firmware recognizes the new CNI module.Do you have a lower price if I buy three of these?
Volume pricing applies. Send your exact quantity to our sales team for a formal quote. Lead times may vary based on current surplus inventory levels.Is this module factory sealed or refurbished?
This is New Surplus. It is factory sealed but may have been stored in a warehouse for several years. We perform a full functional test, including network handshake verification, before shipping.What happens if I install it and the controller won’t boot?
Power down immediately. Verify that the module is fully seated in the backplane. A partially inserted CNI module can cause a backplane fault. Reseat the module and check the controller diagnostic logs.How long does shipping usually take?
We ship verified stock within 24 hours of payment. Transit times depend on your location and chosen freight carrier. Expedited options are available at checkout.Can you test this with my specific Experion software version?
We test against standard Experion C300 firmware baselines. If your system uses a legacy build, send us the software version number. We will note any known compatibility issues before you order.
