Key Technical Specifications Parameter Specification Part Number IS220PRTDH1BC / 336A5026ADP13 Brand GE / GE Vernova Module Type RTD temperature input pack Series GE Mark VIe Speedtronic RTD Inputs Up to 8 per pack (pack-level) A/D Resolution 14-bit (reference spec for PRTDH1 series) Max Lead Resistance 15 Ω Power Supply 28 VDC (approx. 0.18–0.24 A, vendor-claimed)…
Key Technical Specifications Parameter Detail Part Number IS230SNRTH2A Product Type RTD Input Terminal Board (S-Type) Compatible System GE Speedtronic Mark VIe Input Type RTD temperature sensors Terminal Board Type S-Type (simplex/non-TMR terminal board) Interface Connects to Mark VIe I/O pack via pack-to-terminal-board connector Mounting DIN-rail or cabinet-mounted terminal board Application Gas turbine temperature monitoring and…
Key Technical Specifications Parameter Specification Part Number IS420UCSBH4A Product Type Mark VIe UCSB universal controller module Compatible System Mark VIe / Mark VIeS, EX2100e, LS2100e Processor Intel EP80579, 1066 MHz Memory 256 MB RAM + 512 MB Flash (verify per revision) I/O Interface IONet Ethernet to Mark VIe I/O packs Communication Ethernet / IONet; Modbus…
Key Technical Specifications Parameter Specification Model 2213-75TSLKTB Laser Type Ion-type laser module Wavelength 457.9 nm Output Power Up to 75 mW Wavelength Stability Better than 0.1 nm Noise Below 2% RMS Operating Temperature 10 °C to 40 °C Storage Temperature -20 °C to 60 °C Humidity Below 85% RH Weight Approximately 16.82 lb Typical Use…
Key Technical Specifications Parameter Value Module type CPU / Central Processor Control Board System family Yaskawa Motoman XRC Controller Part number DF9203006-C0 Model suffix -1 (revision identifier) Platform XRC robot controller Primary function Motion control, program execution, system coordination Compatible robots Motoman XRC-series robots Mounting Internal controller backplane slot Status Legacy / Obsolete (XRC platform…
Key Technical Specifications Parameter Specification Part Number IS215UCVEM09A Brand GE / GE Vernova Module Type VME-bus CPU controller module Series GE Speedtronic Mark VIe / Mark VI Processor Intel Celeron 300 MHz Memory 16 MB flash, 32 MB DRAM Operating System QNX real-time OS Ethernet 1x 10BaseT/100BaseTX (RJ-45) Serial Ports 2x RS-232C Bus Interface VME…
Key Technical Specifications Parameter Detail Part Number IS215VCMIH2CA Product Type VME Communication Interface Card / VCMI Bus Master Controller Compatible System GE Speedtronic Mark VI Turbine Control Form Factor 6U VME board, 0.787 in. width Processor Texas Instruments TMS320C32 32-bit DSP Memory 32 KB dual-port memory; SRAM and flash (capacity varies by revision) IONet Ports…
Key Technical Specifications Parameter Specification Function Discrete output I/O pack for Mark VIe Channels Up to 12 relay outputs, depending on terminal board Compatible Terminal Boards TRLY and SRLY types; not for DIN-rail DRLY boards Network Interface 2x RJ45 Ethernet ports Power Input 3-pin DC connector, typically 28 VDC Field Connector DC-37 connector to terminal…
Key Technical Specifications Parameter Value Module type Discrete Input I/O Pack (PDIA) System family GE Mark VIe Speedtronic Part number 336A4940CSP1 Discrete inputs Up to 24 channels (terminal-board dependent) Contact wetting voltage 32 VDC typical Supply voltage 27.4 VDC nominal (28 VDC typical) Communication Dual RJ-45 IONet (Ethernet) Configuration tool ToolboxST LEDs Power, ENet1, ENet2,…
Key Technical Specifications Parameter Specification Part Number IS220PAICH2A / 336A4940CSP11 Product Type Mark VIe Analog I/O Pack (PAIC) Compatible System GE Mark VIe Speedtronic control system Analog Inputs 10 channels total Input Range Ch 1–8: 5 V, 10 V, or 4–20 mA; Ch 9–10: 1 mA or 4–20 mA Analog Outputs 2 channels, 0–20 mA;…
