Product Introduction
The GE DS200RTBAG3AHC is a specialized relay terminal board designed for the Mark V turbine control system. This board acts as the critical interface between the control logic and the field devices, housing 10 relays and 52 I/O terminals to manage signal distribution and power switching.Engineered for rugged industrial environments, this module ensures reliable operation within a wide temperature range of -40°C to +70°C. Its compact design and low power consumption (2.6W) make it a vital component for maintaining the efficiency and safety of turbine operations.
Key Technical Specifications
- Series: Mark V Control System
- Relay Count: 10
- I/O Terminals: 52
- Operating Temperature: -40°C to +70°C
- Power Consumption: 2.6W
- Application: Steam Turbine Control · Generator Protection
- Voltage: Typically 120V AC (verify with specific configuration)
- Frequency: 47-63Hz
