BENTLY 106M1081-01 | Proximity Probe Extension Cable | Obsolete Spare Parts Risk Analysis

  • Model: 106M1081-01
  • Brand: Bently Nevada (now part of Emerson Automation Solutions)
  • Core Function: Fixed-length extension cable used in Bently Nevada proximity probe systems to connect 3300 XL or 3300 NSv eddy-current sensors to their associated driver/proximitor modules; provides impedance-matched signal transmission for accurate vibration and position measurement
  • Lifecycle Status: Obsolete / Limited Availability – Officially discontinued by Emerson; superseded by newer cable families with updated connectors or shielding
  • Procurement Risk: High – Genuine OEM units are scarce; secondary market often contains mislabeled, non-impedance-matched, or damaged cables that compromise measurement integrity
  • Critical Role: Essential for reliable operation of machinery protection and condition monitoring systems on critical turbomachinery (e.g., compressors, steam/gas turbines); improper or failed cable causes false vibration readings, nuisance trips, or missed fault detection
Category: SKU: BENTLY 106M1081-01

Description

Key Technical Specifications (For Spare Parts Verification)

  • Product Model: 106M1081-01
  • Manufacturer: Bently Nevada → Emerson
  • System Compatibility: 3300 XL 8 mm Proximity Probe System, 3300 NSv, and legacy 3300/3300 XL systems
  • Cable Length: 31 feet (9.45 meters) — “01” suffix typically denotes this standard length
  • Connector Type:
    • Sensor end: Miniature coaxial twist-lock (Bently P/N 106M0020-01 compatible)
    • Proximitor end: Standard MS-style connector (e.g., MS3112E14-12S or equivalent)
  • Impedance: 50 Ω (critical for signal integrity in eddy-current systems)
  • Shielding: Dual-layer (foil + braid) with 360° backshell grounding at both ends
  • Conductor: Center conductor for signal, outer shield for ground/reference
  • Jacket Material: Polyurethane or PVC, oil- and abrasion-resistant
  • Operating Temp: -30°C to +105°C (industrial grade)
  • Certifications: CSA, ATEX (depending on variant), suitable for Class I Div 2 environments



System Role and Downtime Impact

The 106M1081-01 is not a “smart” component, but it is mission-critical in rotating equipment monitoring. It forms part of the analog signal path between the proximity probe (mounted near a shaft) and the proximitor (which converts probe gap into a -2 to -18 VDC signal). Because eddy-current systems rely on precise RF impedance matching, any deviation in cable capacitance or impedance (e.g., from using a generic coaxial cable) distorts the probe’s output—leading to:

  • False high/low vibration alarms
  • Incorrect shaft position (axial thrust) readings
  • Nuisance trips in machinery protection systems (e.g., 3500 rack)
  • Inability to detect developing faults like rubs, cracks, or imbalance

In a gas compressor station or power plant, such errors can trigger an unplanned shutdown costing $100,000+ per hour—or worse, mask a real failure leading to catastrophic machine damage.



Reliability Analysis and Common Failure Modes

Despite passive design, these cables fail due to harsh industrial environments:

  • Jacket abrasion or cracking: From rubbing against brackets, thermal cycling, or UV exposure (in outdoor installations)
  • Connector corrosion: Moisture ingress at MS or mini-coax connectors causes intermittent signals or increased noise
  • Shield discontinuity: Poor grounding at either end introduces EMI (e.g., from VFDs), corrupting microvolt-level probe signals
  • Internal conductor fatigue: Repeated flexing near probe head leads to open circuits—often intermittent and hard to diagnose

Recommended maintenance practices:

  • Perform annual visual inspection for cuts, kinks, or crushed sections
  • Use a time-domain reflectometer (TDR) or Bently’s TK3-2 calibrator to verify cable integrity during outages
  • Ensure both ends are properly grounded per API 670 guidelines
  • Never coil excess cable tightly—maintain minimum bend radius (>5× diameter)
BENTLY 106M1081-01

BENTLY 106M1081-01

Lifecycle Status and Migration Strategy

Emerson has discontinued the 106M1081-01 and consolidated cable offerings under newer part numbers (e.g., 106M1081-51, 106M1081-03, or 3300 NSv-specific cables). While some distributors still list new-old-stock (NOS), authenticity is a growing concern.

Procurement risks:

  • Generic “Bently-compatible” cables often lack true 50 Ω impedance → cause calibration drift
  • Used cables may have hidden internal damage
  • Mismatched connectors require adapters, introducing signal reflections

Interim mitigation strategies:

  • Maintain a cable test log with baseline TDR traces for each installed run
  • Stock verified genuine spares with original packaging and lot traceability
  • Use heat-shrink boots and strain reliefs to extend service life

Long-term migration path:

  • For new installations: Transition to 3300 NSv or Velomitor® systems with digital outputs (e.g., 1900/65A) that reduce analog cabling dependency
  • For retrofits: Consider wireless vibration sensors (e.g., Emerson AMS Wireless) for non-safety monitoring loops
  • Do not replace with non-Bently cables in machinery protection (API 670) applications—this violates compliance and voids system certification

Final Recommendation

The BENTLY 106M1081-01 is a deceptively simple but high-consequence component. Its obsolescence demands proactive management:

✅ Immediately audit all installed cables and label with installation date
✅ Secure 2–3 genuine spares per critical machine train while available
✅ Document baseline performance using a TK3 or portable monitor
✅ Train technicians to recognize cable-induced anomalies (e.g., noise spikes at 60 Hz harmonics)
